LYNN CPCS-6-005F CAT6 Choice Slim Ethernet (28AWG) Patch Cable - 5 ft

Home > Connectivity > Patch Cables > Cat 6 >

Alternative Views:

Price: $4.52

Your Price: $4.29

Savings: $0.23

Product Code: CPCS-6XX-005F

Color

Qty:

Description

LYNN CPCS-6-005F CAT6 Choice Slim Ethernet (28AWG) Patch Cable - 5 ft

Designed for 10/100/1000BASE-T and 10 Gbps networks. All network patch cables are pure copper with gold plated contacts.Every cable is UL listed, CM rated and Fluke tested ensuring the highest level of performance. Operating temperature of -4° to 140°. Data Rate Support of up to 10 Gbps and Frequency Bandwidth of 500 MHZ.

Features:

Less than half the size of standard CAT6 patch cables
40% smaller bend radius simplifies routing through panels
Low profiles connector for easy installation in high-density data centers
Vibrant colors to easily color-code your network installation

Construction:

Cable Type: Slim Cat6 Booted
Conductor Type: 28 AWG Stranded Tinned Copper
Cable Jacket: PVC CM
Shielding Type: Unshielded (UTP)
Connectors: RJ45 Male 50mμ gold-plated
Insulation: High density polyethylene, .005" nominal wall thickness

POE Specifications:

POE: 350mA, 12.95W, Max distance 40mPOE+: 600mA, 25.5w, Max distance 40mPOE++: 1,000mA, 96W, Max Distance 40m

Approvals:

UL Listed
RoHS Compliant
ANSI/TIA 568 C.2 Category 6
ISO 11801 Class E Edition 2.1
